Construction of High-End Intelligent Glass Greenhouses - High Efficiency and Low Effort

Hot-dip galvanized special steel for greenhouse, sturdy and durable, with a quality guarantee period of 20 years; mainly includes:

★ The main columns are 120mm × 120mm × 3.0mm hot-dip galvanized rectangular steel pipes

★ The end main columns and corner columns are 120mm × 120mm × 3.0mm hot-dip galvanized rectangular steel pipes

★ The side and end secondary columns are 120mm × 60mm × 2.0mm hot-dip galvanized rectangular steel pipes

★ The 12-meter horizontal trusses are 50mm × 50mm × 2.5mm rectangular steel pipes and 30mm × 30mm × 3mm angle steel, processed and then overall hot-dip galvanized for anti-corrosion treatment.

★ The water trough is made by pressing φ2.5mm cold-rolled hot-dip galvanized steel plate.

★ The roof truss rods are 50mm × 30mm × 2mm hot-dip galvanized rectangular tubes;

★ The ridge is made of greenhouse-specific aluminum alloy ridge;

★ The surrounding purlins are 50mm × 50mm × 2mm hot-dip galvanized rectangular steel;

The bottom plates of the columns δ = 10mm are steel plates, and the columns are welded to the bottom plates (users can use concrete plastering for anti-corrosion in the later stage).

The connecting parts are all made of cold-formed hot-dip galvanized steel plates.

Domestic aluminum alloy frames and connecting bolts, nuts and washers
